Brief:
My very basic design t' make t' most out o' AeroTech's G55-10 motor. Arrr! Aye aye!

Construction:
Use 1 piece o' 24mm LOC Motor Mount Tube, 20 inches long. Avast! It is cut 2 inches above t' forward end o' t' inserted G55.

Use a spent Estes "D" motor, me hearties, hollowed out, shiver me timbers, arrr, epoxied as a thrust rin' / shockcord mount. Begad! Avast, me proud beauty! T' remainin' body tube is epoxied onto the "D-motor thrust ring." Add a basic (or nay so basic) nose cone for Estes 24mm tube.

My shockcord leader is made from Steel Fishin' Leader, me hearties, arrr, threaded through the spent D motor casin' and 5 inches long. Well, blow me down! Then an elastic shockcord is connected to leader and nose cone. Avast! Blimey! T' nose cone filled with epoxy and eyebolt added to attach t' shockcord.

I didn't use any retainment other than a piece o' maskin' tape wrapped once around t' motor.

I used very short, angled launch lugs, arrr, cut from First Fire igniter tubes.

T' 4 fins are from 5 ply, matey, 1/8 inch aircraft plywood, shiver me timbers, with beveled leading edges and tip chords. Avast, me proud beauty! Blimey! I rounded t' trailin' edge. Ahoy! Blimey! They are attached with double epoxy fillets.

A very easy build, me hearties, me hearties, completed in less than 3 hours with fins cut usin' a power hand saw.

I spray painted it red until it drips with evident drip marks (for effect).

Flight:
It be designed for it, so t' motor I used be a G55-10 single use. I used Estes waddin' t' protect t' shockcord and streamer. Well, blow me down! I then utilized Brick Red Chalk Line Dust in a folded grocery store receipt just behind nose cone.

T' ejection charge caused t' elastic shockcord t' cut itself on t' steel shock cord leader. Aye aye! T' nose cone was lost, t' body free fell out o' sight. Aye aye! Ya scallywag! It was miraculously recovered about 1/2 mile away. Blimey! If it weren't for t' tracking powder, we wouldn't have even seen ejection.

Awesome flight, super fast, super straight. A real crowd pleaser. Arrr! Blimey! RockSim speed be estimated at 835 mph and altitude was approx. Begad! Blimey! 5300 feet.

Summary:
This rocket was super easy t' build. T' Estes "Nemesis" nose cone fits into t' body tube and will be t' next nose cone. Aye aye! So with 1 more G55-10 motor, she'll fly one more time on that motor.
